Low Voltage Cable

Type of Cable :

NYA (Cu/PVC)

Detail Contructions :

Copper
Conductor, PVC Insulated

Standard Specification :

SNI 04-6629.3
: 2006

Size :

Single Core 1C
x (1.5-300) mm²

Rate Voltage :

450/750V

Application :

For building
wire installed in conduit in dry location and interwiring in swich board and
control panel

Special Features on Request :

• Fire
Resistance

• Oil
Resistance

• UV
Resistance

• Flame
Retardant Cat. A, B, C

• Flame
Retardant Non Category

• Heat
Resistance

• Anti Termite

• Anti Rodent

• Low Smoke
Zero Halogen

• Nylon Coated

Conductor Shape :

1.5 – 10 sqmm
supplied in solid (re) or non compacted circular stranded (rm) conductor shape.

16 – 300 sqmm
supplied in non compacted circular stranded (rm) conductor shape.

Standard Packing :

1.5 – 16 sqmm
supplied in coil @ 100 m

25 – 300 sqmm
supplied in wooden drum @ 1000 m

Length
Tolerance per drum ± 2%
